VMC Frame

                   Accuracy standard implemented: ISO10791-2:2001 (JB/T8771.1998).

              Smartech supplys both frame and complete machine, below is the introduction of frame.
  • Standard Components:
    1.    High-quality castings processed with resin sand and wooden molds ;
    2.    Harden & ground on Z guideway and Turcite-B coated with precise scraping, Hiwin, PMI or INA linear guidways on X, Y axes;.
    3.    Hiwin, PMI, BSG or HPS (brand of) ball screws,
    4.    NSK or FAG bearings for supporting ball screws ;
    5.    Royal or POSA spindle, 8000 rpm, blet-type drive ;
    6.    Beijyu or Haocheng brand of tool unclamping system ;
    7.    R&W couplings from Germany ;
    8.    Keyarrow (Taiwan) brand of telescopic covers, stainless steel cover on all axes ;
    9.    Centralized lubrication system of Byjur or HERG brand ;
    10.  Coolant system installed.
    * Same price for all the brands mentioned.
    Optional Components:
    1     10000 rpm or 12000 rpm Spindle ;
    2     Direct drive structure for main motor with spindle ;
    3     Central oil coolant for the spindle ;
    4     Coolant through spindle ;
    5     Coolant pump of Taiwan brand Walrus ;
    6     Outside guarding, standard or specially designed for client ;
    7     Chip conveyor: helix type, chain type ;
    8     CNC pre-installed for client, complete machine ready to use ;
    9.    ATC: drum type, arm type or chain type.
